Intel Core i5-12400, CPU, Socket 1700, 6 Cores/12 Threads Retail

CPU Specifications

• Total Cores 6
• # of Performance-cores 6
• # of Efficient-cores 0
• Total Threads 12
• Max Turbo Frequency 4.40 GHz
• Performance-core Max Turbo Frequency 4.40 GHz
• Performance-core Base Frequency 2.50 GHz
• Cache 18 MB Intel Smart Cache
• Total L2 Cache 7.5 MB
• Processor Base Power 65 W
• Maximum Turbo Power 117 W

Memory Specifications

• Max Memory Size (dependent on memory type) 128 GB
• Memory Types Up to DDR5 4800 MT/s
• Up to DDR4 3200 MT/s
• Max # of Memory Channels 2
• Max Memory Bandwidth 76.8 GB/s
• Processor Graphics
• Processor Graphics Intel UHD Graphics 730
• Graphics Base Frequency 300 MHz
• Graphics Max Dynamic Frequency 1.45 GHz
• Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
• Execution Units 24
• Max Resolution (HDMI) 4096 x 2160 @ 60Hz
• Max Resolution (DP) 7680 x 4320 @ 60Hz
• Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 @ 120Hz
• DirectX* Support 12
• OpenGL* Support 4.5
• OpenCL* Support 3.0
• Multi-Format Codec Engines 1
• Intel Quick Sync Video Yes
• Intel Clear Video HD Technology Yes
• # of Displays Supported 4
• Device ID 0x4692 / 0x4682

Expansion Options

• Direct Media Interface (DMI) Revision 4.0
• Max # of DMI Lanes 8
• Scalability 1S Only
• PCI Express Revision 5.0 and 4.0
• PCI Express Configurations Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes 20

Package Specifications

• Sockets Supported FCLGA1700
• Max CPU Configuration 1
• Thermal Solution Specification PCG 2020C
• TJUNCTION 100C
• Package Size 45.0 mm x 37.5 mm

Advanced Technologies

• Intel Gaussian & Neural Accelerator 3.0
• Intel Thread Director No
• Intel Deep Learning Boost (Intel DL Boost) Yes
• Intel Optane Memory Supported Yes
• Intel Speed Shift Technology Yes
• Intel Turbo Boost Max Technology 3.0 No
• Intel Turbo Boost Technology 2.0
• Intel Hyper-Threading Technology Yes
• Intel 64 Yes
• Instruction Set 64-bit
• Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2
• Idle States Yes
• Enhanced Intel SpeedStep Technology Yes
• Thermal Monitoring Technologies Yes
• Intel Volume Management Device (VMD) Yes

Security & Reliability

• Intel Threat Detection Technology (TDT) Yes
• Intel Standard Manageability (ISM) Yes
• Intel Control-Flow Enforcement Technology Yes
• Intel AES New Instructions Yes
• Secure Key Yes
• Intel OS Guard Yes
• Execute Disable Bit Yes
• Intel Boot Guard Yes
• Mode-based Execute Control (MBEC) Yes
• Intel Virtualization Technology (VT-x) Yes
• Intel Virtualization Technology for Directed I/O (VT-d) Yes
• Intel VT-x with Extended Page Tables (EPT) Yes
